Dolphin Fluidics proportional valves are normally closed valves with on/off and proportional control. The valves integrate digital electronics enabling closed loop proportional control of the fluid flow, eliminating any performance drift during operation, thus ensuring extremely high positioning accuracy and flowrate control.



Dolphin’s produces several types of electronically controlled proportional valves, each with its unique characteristics and advantages.



Proportional valve types

Single-channels proportional valve


single channels proportional valve

Single-channel proportional control valve is a smart valve that operates digitally, featuring on/off and proportional closed-loop control. Proportional single valves are two ways valves, which are capable of completely separating the fluid path. They are ideal for dosing or dispensing both gas and liquids with high accuracy, and exhibit no drift over time. Moreover, the design of each valve can be easily customized on functional requirements of various applications.



 Discover more

Dual-channels proportional valve


dual channels proportional valve

Dolphin Fluidics offers dual-channels electronically controlled proportional valves consisting of two separate channels in and out, each featuring normally closed, on/off, and proportional closed-loop control. They are well-suited for applications involving dosing, dispensing, or mixing fluids, whether gases or liquids, with exceptional precision and no time drift. As they enable independent control of two channels, dual-channel valves serve as true fluid modules that are integrated into a single device, thereby allowing customers to minimize space, weight, wiring, and consequently, costs associated with their equipment.



 Discover more

Hydraulic proportional valve

A hydraulic proportional valve’s main function is to determine a change in flow or in pressure, regulated by the opening of a plunger. Typically, the change in flow is determined by the displacement of the moving element, which is actuated by a shape memory electrical actuator.




hydraulic proportional valve

Working principle

How do proportional hydraulic valves work? Electronically controlled hydraulic proportional valves have an important point of divergence from on-off control valves. While in the latter the actuator can assume only two positions-total opening and total closing, in hydraulic proportional valves, it can also position itself at intermediate levels. This allows hydraulic flows to flow in a proportional and controlled manner.



Dolphin Fluidics' hydraulic proportional valves find wide use not only in electromedical machines but also in intelligent sanitary systems, faucets, and various professional devices in the food & beverage industry.

Proportional water valve


proportional water valve

Proportional water flow valve is a normally closed, 2-way valve that incorporates proportional closed-loop control. Dolphin offers the Smart HP Liquid, an optimal solution for precise dosing or dispensing of liquids, including water, even under high pressure, without any drift over time. It is also characterized by its low power consumption, which is up to 20 times less than conventional solenoid valves, as well as its silent operation. Moreover, this water-proportional flow control valve can be interfaced directly with external sensors measuring pressure, flow, or temperature. This allows for closed-loop control to ensure the target fluid dynamic function is achieved.



 Discover more

Proportional gas valve


proportional gas valve

Dolphin’s proportional gas valve offers a precise and consistent solution for dosing or dispensing gas, with no time drift. Customization of each valve is effortless to ensure they meet even the most demanding functional requirements of various applications. This includes adjustment of the electronic and mechanical interface, fluidic performance, and control electronics and communication on IoT platforms. Depending on the industry, single-channel or two-channel valves are ideal for dosing or dispensing gas.



 Discover more

Understanding the proportional valve working principle

Due to the integration of flow, pressure, and temperature sensors, and through dedicated firmware Dolphin Fluidics proportional valves are able to control the customer's target function in a closed loop.



The valves can autonomously dose, dispense, profile, or mix based on the signal received from the connected sensors. Furthermore, because digital electronics control the proportional valves, they can be easily connected, via serial bus or wireless protocols, to IoT cloud and mobile platforms enabling remote data exchange, management, and diagnostics.

Advantages of Dolphin Fluidics proportional valves

“DF Smart Valve” VS “Solenoid Valve”

Dolphin Fluidics valves are the smartest, quietest, lightest, smallest, most hygienic, and most efficient solution for proportional control of flows, pressures, and temperatures of both air and liquids. Dual-channel valves, as opposed to single-channel valves, are digital smart valves with 2 separate channels each with on/off and proportional closed-loop control.



These valves are the perfect solution for dosing, dispensing, or mixing fluids, both gas and liquids, with high precision and zero drift over time. Each valve can be easily customized to meet the most stringent functional requirements of various applications, in terms of interface, fluid performance, and control electronics.



The use of shape memory actuation technology and digital electronics for control and communication allows the development of devices unique in performance and with clear advantages over standard technologies on the market today.

Dolphin Smart Valve
Solenoid valve
Cleanless
Power saving
Weight saving
Kv
Noiseless operation
Space saving
Design modularity
Proportional control accuracy
Learn about Dolphin Fluidics technology

Dolphin Fluidics valves are the smartest, quietest, lightest, smallest, most hygienic, and most efficient solution for proportional control of flows, pressures, and temperatures of both air and liquids. Dual-channel valves, as opposed to single-channel valves, are digital smart valves with 2 separate channels each with on/off and proportional closed-loop control.



These valves are the perfect solution for dosing, dispensing, or mixing fluids, both gas and liquids, with high precision and zero drift over time. Each valve can be easily customized to meet the most stringent functional requirements of various applications, in terms of interface, fluid performance, and control electronics.



The use of shape memory actuation technology and digital electronics for control and communication allows the development of devices unique in performance and with clear advantages over standard technologies on the market today.

Cleanless
Total separation valve
Minimum wetted surface
Power saving
< 1W
At least 10 times less than conventional valves
Weight saving
Only 50g
The lightest electronic valve on the market
Kv
0,05- 0,5 (m3/h)/√bar
High flows at low pressures
Noiseless operation
0 db
Totally silent operation
Space saving
“all in one”
Total integration of fluidics and electronics
Design modularity
Modular fluidics, electronics and mechanics
Completely customisable
Proportional control accuracy
+/- 1%
Closed-loop control
